DE NEEF® waterproofing injection solutions

Leaks stop here: Fast, proven, durable.

The DE NEEF® portfolio provides waterproofing injection solutions that stop leaks under any circumstances and in any application--foundations, infrastructure and more. Nobody plans for a leak, so when one occurs it usually represents a cost overrun and a setback for a construction project. The ability to quickly and permanently stop a leak in any part of a construction is therefore invaluable for contractors and owners.

Documents

DE NEEF® Product Documents

Product Name Product Data Sheet SDS/MSDS
DARACEM® 19CFMQ
Product Data Sheet
DE NEEF® DENEPOX 40 CE
Product Data Sheet
SDS/MSDS
DE NEEF® Gelacryl Superflex AR
Product Data Sheet
DE NEEF® HA CUT AF
Product Data Sheet
DE NEEF® HA CUT CFL AF
Product Data Sheet
DE NEEF® HA Flex LV AF
Product Data Sheet
DE NEEF® HA Flex SLV AF
Product Data Sheet
DE NEEF® HA SAFEFOAM NF
Product Data Sheet
DE NEEF® HA SOIL AF
Product Data Sheet
DE NEEF® Pipe Plug
Product Data Sheet
DE NEEF® Washing Agent
Product Data Sheet
Elastopack 201
Product Data Sheet
SDS/MSDS
Epicol T
Product Data Sheet
GELACRYL™ AR
Product Data Sheet
GELACRYL™ TI
Product Data Sheet
Multitek Adhesive SDW
Product Data Sheet
OMNITEK® Deco
Product Data Sheet
OMNITEK® RM Fiber
Product Data Sheet
TYTRO SI 550
Product Data Sheet

Product Brochure

Product Name PDF
DE NEEF® Municipal Brochure
Products & Accessories

Products

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
DARACEM® 19CFMQ
Description

DARACEM® 19CFMQ is a high performance liquid concrete superplasticiser that has been developed to impart extreme workability to concrete mixes so that large or difficult pours can be made, whilst maintaining excellent slump retention properties, especially under hot climatical conditions.

Key Benefits
  • High compressive strength concrete especially at early ages.
  • High workability concrete mix with DARACEM 19CFMQ will have the same or higher compressive strength compared to plain concrete of similar w/c ratio.
  • Plastic concrete exhibits high cohesion, fluidity and flowability.
Application Type
DE NEEF® DENEPOX 40 CE
Description

Two-component epoxy resin, which cures into a rigid compound in wet and dry conditions.

Key Benefits
  • Insensitive to humidity.
  • Cures in damp/wet environment.
  • Low viscosity: deep penetration in the cracks.
Application Type
  • Low pressure injection for the structural bonding of cracks and microcracks in dry or wet concrete.
  • Bonding and anchoring.
  • Sealing of porous low density concrete.
  • DE NEEF® Denepox 40 is not suited for applications in contact with moving water.
DE NEEF® Gelacryl Superflex AR
Description

Superflex AR is a system composed of Superflex methacrylic acrylate copolymer resin and DeNeef Reinforcing Agent.

Key Benefits
  • Low viscosity\
  • Reduced shrinkage
  • NSF/ANSI 61 Certified for use with potable water
Application Type
  • Hairline & spider cracks in concrete
  • Re-injection of failed polyurethane grout
  • Expansion & moving joints
DE NEEF® HA CUT AF
Description

DE NEEF® HA Cut AF is a next generation 1-component injection resin with improved waterproofing and water cutting performance.

Key Benefits
  • ADR free transport
  • Next generation resin with improved waterproofing performance.
  • Improved cell structure of the cured compound resulting in better mechanical properties and durability.
Application Type
  • Used to block water leaks in diaphragm walls.
  • Filling large voids
  • Injection of LDPE or HDPE membranes in tunnel construction
DE NEEF® HA CUT CFL AF
Description

HA CUT CFL AF is a next generation 1- component injection resin with improved waterproofing and water cutting performance.

Key Benefits
  • ADR free transport.
  • Next generation resin with improved waterproofing performance.
  • Improved cell structure of the cured compound
Application Type
  • Designed for cutting off gushing water leaks
  • Used to block leaks into diaphragm walls.
  • Filling large voids
DE NEEF® HA Flex LV AF
Description

In its uncured form, HA Flex LV AF is a yellow, non-flammable liquid without phthalate plasticisers. HA Flex LV AF is a next generation 1-component injection resin with improved waterproofing performance.

Key Benefits
  • Complies with EN 1504-5, Principle D.
  • ADR-free transport.
  • Next generation resin with improved waterproofing performance.
Application Type
  • For stopping water leaks through joints between tunnel segments.
  • For injection of the LDPE or HDPE membrane in tunnel constructions.
  • For curtain injections behind tunnel segments
DE NEEF® HA Flex SLV AF
Description

In its uncured form, HA Flex SLV AF is a yellow, non-flammable liquid without phthalate plasticisers. HA Flex SLV AF is a next generation 1-component injection resin with improved waterproofing performance.

Key Benefits
  • Next generation resin with improved waterproofing performance.
  • Improved cell structure of the cured compound resulting in better mechanical properties and durability.
  • Non-phthalate resin REACH compliant.
Application Type
  • For stopping water leaks through joints between tunnel segments.
  • For injection of the LDPE or HDPE membrane in tunnel constructions.
  • For curtain injections behind tunnel segments
DE NEEF® HA SAFEFOAM NF
Description

HA SAFEFOAM™ NF is a single component, phthalate free, low viscosity, hydrophilic, polyurethane resin.

Key Benefits
  • ADR free transport
  • Phthalate free resin, REACH compliant
  • Non-flammable
Application Type
  • For sealing dry, moving, non-structural cracks
  • For sealing moist, moving non-structural cracks
  • For sealing water leaks between the joints of concrete tunnel segments
DE NEEF® HA SOIL AF
Description

HA Soil AF is a dark brown, non-flammable, low viscous liquid without phthalate plasticiser that expands and quickly (depending on temperature and the amount of HA Soil Cat AF catalyst used) cures to a rigid polyurethane foam.

Key Benefits
  • ADR free transport
  • Next generation resin with improved performance
  • Phthalate-free resins, REACH compliant
Application Type
  • Used for stabilising loose soils or to increase the load bearing capacity of these soils.
DE NEEF® Pipe Plug
Description

In its uncured state the 1-component resin grout is a dark brown, non-flammable liquid. When the product is mixed, and after being soaked into water, it expands and cures into a rigid closed-cell polyurethane foam.

Key Benefits
  • Solvent free.
  • User friendly: all components in 1 kit.
  • The cured foam is resistant to most organic solvents, mild acids, alkaloids and micro-organisms.
Application Type
DE NEEF® Washing Agent
Description

Washing Agent Eco is a mixture of non-volatile, chlorine-free, non-toxic organic solvents for cleaning equipment and substrates of PU and epoxy resins, adhesives and paints.

Key Benefits
  • C Virtually non-flammable.
  • Chlorine-free.
  • Non-hazardous solvent.
Application Type
Elastopack 201
Description

ELASTOPACK 201 is a 2-component, phthalate free, injection grout consisting of a resin and a hardener, which are injected as 1-component system after mixing. After curing, the grout will become a dense and elastic material.

Key Benefits
  • ADR free transport
  • Phthalate free resin, REACH compliant
  • Packed as a complete pre-weighted set
Application Type
Epicol T
Description

2-component sag-free epoxy compound.

Key Benefits
  • Good adhesion to wet surfaces, even for underwater application without the presence of high water pressure.
  • Very good mechanical properties.
  • Cures without shrinking.
  • Easy to mix and use.
  • Adhesion to wood, stone, and concrete; surpasses material cohesion.
Application Type
GELACRYL™ AR
Description

GELACRYL™ Acrylic Rubbers are 2-component poly-acrylate gels. The A-component is a poly-acrylate resin, the B-component is a polymer blend. The 2-components are injected with a 2-component 1:1 ratio piston pump. Once polymerised, GELACRYL™ Acrylic Rubbers form a resilient, highly elastomeric gel. Due to their exceptionally low viscosity and low surface tension, GELACRYL™ Acrylic Rubbers show better penetration into cracks than water.

Key Benefits
  • GELACRYL™ AR injection systems are injected with a twin piston, 1:1 ratio pump.
  • Exceptionally low viscosity. GELACRYL™ AR penetrates into cracks 0.1 mm wide.
  • Excellent post-expansion properties in contact with water.
Application Type
GELACRYL™ TI
Description

GELACRYL™ TI is a special 3-component poly-acrylate injection resin developed specifically for injection of preventative injection tubes.

Key Benefits
  • Easy to use 3-component system
  • Long gel time allows controlled injections
  • Linear viscosity increase
Application Type
  • Injection and re-injection of preventative injection tubes.
Multitek Adhesive SDW
Description

Multitek™ Adhesive SDW is a universal, solvent free, thixotrope, 2-component epoxy adhesive.

Key Benefits
  • Adhesion to wood, stone and concrete surpasses material cohesion
  • Multitek Adhesive SDW is solvent free
  • Fast curing, even at low temperatures
Application Type
  • Application of Colfex™ waterproofing tape on dry surfaces.
  • For gluing in thin layers or repairing pre-cast concrete elements, wood, metal, porous stone, natural stone, etc.
OMNITEK® Deco
Description

OMNITEK® Deco is a high strength, cement based, volume stable mortar, suitable for levelling and finishing of concrete surfaces in layer thicknesses of 2-5mm.

Key Benefits
  • High early- and final strength properties to strength class C45/55 and excellent adhesion to concrete
  • Fast, easy and cost effective application
  • CE certified according to EN 1504-3.
Application Type
  • Surface levelling and finishing of vertical and horizontal concrete surfaces
  • Surface re-profiling applications of joints, edges and damaged precast elements and concrete structures.
OMNITEK® RM Fiber
Description

OMNITEK® RM Fiber is a fiber reinforced, high strength, high-sulphate resistant cement based, volume stable repair and re-profiling mortar, suitable for concrete repair in demanding environments in the safest, most targeted and productive way in layer thicknesses of 10-50mm.

Key Benefits
  • High early- and final strength properties to strength class C60/75
  • Polymer modified for an excellent adhesion, and fiber reinforced
  • High carbonatation, chloride, freeze-thaw and chemical resistance
Application Type
  • General concrete repairs in vertical and horizontal conditions
  • Repair of concrete structures exposed to sea water, corrosive environments or severe freezing conditions.
TYTRO SI 550
Description

(Formerly DE NEEF® Organosol 550 DT) Fast reacting, non-foaming, two-component urea-silica injection grout.

Key Benefits
  • Non-expanding, safe for weak strata and soils.
  • Reacts underwater without dilution.
  • High bond and compressive strength.
Application Type
  • Bonding and consolidating strata in underground constructions such as tunnels.
  • Bonding and consolidating strata in mining operations such as long walls, mine seals and shafts.
  • Soil and rock injections where nonexpanding grouts are required.
Overview

Seal leaks almost as fast as they appear

The major advantages of DE NEEF® products include the fact that they are easy to use, are not diluted and can be applied quickly and reliably. The portfolio is mostly based on single-component, closed cell, hydrophobic polyurethanes, which are both durable and lasting. Therefore, leaks that are stopped once will remain stopped. For taking care of leaks that slow down the progress of a job site, endanger the future of a construction, or prevent full use of a building, DE NEEF® has become the world's most trusted brand.

Solutions for every leak

DE NEEF® has a variety of formulations for a number of different applications:

  • For owners who need to repair and maintain buildings and infrastructure projects
  • For contractors who need to shore up deep foundations during excavation
  • For installers and applicators who are charged with specialised leak repair

In every case, there's a DE NEEF® solution that's best-suited for the task at hand—including deep foundations, underground spaces, tunnels, mass rapid transport infrastructure and sewer repair applications.

Solutions for every structure

Concrete or masonry—no matter which type of construction, DE NEEF® can fix the leak. From the ground breaking through completion, DE NEEF® products can be used for soil injections and water control and remediation. DE NEEF® solutions can also be used during excavation or tunnel boring. DE NEEF® products can be used in every stage of underground construction.

Certified around the globe

We have done extensive testing of DE NEEF® products to ensure that performance claims are backed up in the field. DE NEEF® products have multiple certification levels including CE certification for use in the European Union, and have potable water certifications from around the world.

Supported globally, available locally

No two leaks are exactly the same—the only thing that any two leaks have in common is that they have to be fixed as fast as possible. The DE NEEF® portfolio offers solutions for all possible challenges in leak sealing and soil injections. With local availability, there's no waiting for the product to arrive—DE NEEF® is readily available.

With a global sales and technical support staff, contractors can trust that DE NEEF® solutions will perform. Don't wait for leaks to slow you down—contact GCP today to learn how to use DE NEEF® on your project.

Leaks Stop Here. Fast. Proven. Durable.
